5mm Stainless Steel Rust-proof Pitch Timing Pulleys

Name: 5mm Stainless Steel Rust-proof Pitch Timing Pulleys
Brand: UMA ENGINEERING
Price: 300.00 INR
Availability: InStock

Price 300.00 INR/ Piece

Get a Price/Quote

MOQ : 20 Pieces

5mm Stainless Steel Rust-proof Pitch Timing Pulleys Specification

Bore
Customizable (Available in various metric and inch sizes)

Load Capacity
Up to 80 Kg (Depending on size and material) Kilograms (kg)

Number Of Grooves
From 12 up to 72 teeth (varies by model)

Bearing Type
Plain Bore (No integrated bearing)

Diameter
20 mm - 120 mm (various sizes available) Millimeter (mm)

Features
Corrosion Resistant, Precision Machined, Wear Resistant, Lightweight

Mounting Type
Center Bore / Keyway / Set Screw

Application
Power Transmission, Linear Motion, Automation, Industrial Machinery

Power Source
Mechanical

Pulley Type
Timing Pulley

Usage
Industrial

Material
Aluminum, Steel

Size
Various Sizes Available

Product Type
Timing Pulley

Color
Different Available

Belt Compatibility
Synchronous timing belt

Width
10 mm, 15 mm, 20 mm (customizable as per belt)

Finish
Anodized for Aluminum, Zinc Plated for Steel

Tolerance
ISO standard

Surface Treatment
Anodizing, Black Oxide

Pitch
5 mm (HTD/STD/MXL/XL types available)

Hub Style
Pilot Bore, Stock Bore, or Taper Lock available

Tooth Profile
HTD, GT2, AT5 options

Operating Temperature
-20C to +120C

5mm Stainless Steel Rust-proof Pitch Timing Pulleys Trade Information

Minimum Order Quantity
20 Pieces

FOB Port
AHMEDABAD

Supply Ability
5000 Pieces Per Month

Delivery Time
10 Days

Sample Available
Yes

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
Standard Packing & As Per Client's Requirement.

Main Export Market(s)
Asia, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001:2015

About 5mm Stainless Steel Rust-proof Pitch Timing Pulleys

Condition - New
Material - Stainless Steel
Quality - Premium

PART NO	PULLEY SIZE	PULLEY TYPE	MATERIAL	NO. OF TEETH	PD	A	HD	PW	L	MIM BORE (D)	MAX BORE	APPROX WEIGHT (kg)
N0360	12-5M-09	1F	STEEL	12	19.10	23	12	14.5	20	4	7	0.03
N0361	14-5M-09	1F	STEEL	14	22.28	25	13	14.5	20	6	8	0.04
N0362	15-5M-09	1F	STEEL	15	23.87	28	16	14.5	20	6	10	0.05
N0363	16-5M-09	1F	STEEL	16	25.46	28	16.5	14.5	20	6	11	0.06
N0364	18-5M-09	1F	STEEL	18	28.65	32	20	14.5	20	6	13	0.07
N0365	20-5M-09	1F	STEEL	20	31.83	36	23	14.5	22.5	6	14	0.10
N0366	21-5M-09	1F	STEEL	21	33.42	38	24	14.5	22.5	6	15	0.12
N0367	22-5M-09	1F	STEEL	22	35.01	38	25.5	14.5	22.5	6	16	0.13
N0368	24-5M-09	1F	STEEL	24	38.20	42	27	14.5	22.5	6.00	18	0.15
N0369	26-5M-09	1F	STEEL	26	41.38	44	30	14.5	22.5	6	20	0.18
N0370	28-5M-09	1F	STEEL	28	44.56	48	30.5	14.5	22.5	6	20	0.21
N0371	30-5M-09	1F	STEEL	30	47.75	51	35	14.5	22.5	6	24	0.25
N0372	32-5M-09	1F	STEEL	32	50.93	54	38	14.5	22.5	8	26	0.28
N0373	36-5M-09	1F	STEEL	36	57.30	60	38	14.5	22.5	8	26	0.33
N0374	40-5M-09	1F	STEEL	40	63.66	70	38	14.5	22.5	8	26	0.42
N0375	44-5M-09	1F	STEEL	44	70.03	75	45	14.5	25.5	8	33	0.54
N0376	48-5M-09	1F	STEEL	48	76.39	80	50	14.5	25.5	8	38	0.65
N0377	60-5M-09	1F	STEEL	60	95.49	100	65	14.5	25.5	8	53	1.05
N0378	72-5M-09	1F	STEEL	72	114.59	120	80	14.5	25.5	8	68	1.54

Versatile Tooth Profiles for Optimal Engagement

Choose from HTD, GT2, or AT5 tooth profiles to achieve maximum grip and minimal backlash in your power transmission or automation setup. These profiled pulleys are engineered to seamlessly match various synchronous timing belts and are customizable in both width and diameter for your specific equipment needs.

Robust Materials and Surface Treatments

Select between high-strength aluminum and steel constructions, each processed with anodized or zinc-plated finishes for superior corrosion resistance and longevity. For additional surface options, black oxide treatment and custom color finishes are also available, ensuring the pulleys withstand demanding industrial environments.

Customization for Industrial Applications

With bore sizes that can be tailored in both metric and inch measurements, and mounting options such as center bore, keyway, or set screw, these pulleys adapt to a wide array of industrial power transmission or automation applications. Hub styles including pilot bore, stock bore, or taper lock provide further installation flexibility.

FAQs of 5mm Pitch Timing Pulleys:

Q: How do I select the correct timing pulley for my application?

A: Determine your required pitch (5 mm), tooth profile (HTD, GT2, or AT5), and compatible belt width. Then, choose the material (aluminum or steel) based on your load and environmental conditions, select the appropriate hub style and bore type, and ensure surface treatments meet your corrosion resistance needs.

Q: What types of timing belts are compatible with these pulleys?

A: These timing pulleys are designed for use with synchronous timing belts matching 5 mm pitch, including compatible HTD, GT2, and AT5 belt profiles. Ensure your belt width aligns with the pulleys available or custom sizing options.

Q: Where can these pulleys be applied within industrial settings?

A: They are ideal for power transmission systems, linear motion assemblies, automation machinery, conveyors, and other industrial equipment requiring precise torque control and synchronized movement.

Q: When should I consider customizing the bore or diameter?

A: Customization becomes necessary when your application requires a non-standard shaft size or specific fit to maximize mechanical efficiency and alignment in various setups, especially in custom automation or retrofit projects.

Q: What process is used to enhance the pulleys corrosion resistance?

A: Aluminum pulleys are anodized while steel pulleys undergo zinc plating or black oxide treatment. These surface processes increase longevity and reduce wear in harsh industrial environments.

Q: How does the pulleys material affect its performance?

A: Aluminum pulleys are lightweight and corrosion-resistant, suitable for high-speed, lightweight applications. Steel pulleys offer higher load capacity and wear resistance, making them ideal for heavy-duty or high-torque environments.

Q: What are the main benefits of using these precision machined timing pulleys?

A: Users benefit from accurate power transmission, reduced slippage, and reliable synchronizationresulting in longer component life, improved process repeatability, and maintenance of industrial standards in various mechanical systems.
